Specifications:
| Configurations | |
|
Dimensions |
Height (With casters) 139cm±1cm
Width 90cm±1cm Depth 71cm±1cm Safe shelf loading 25kg±0.5kg |
| Display | 8.4 inch TFT LCD touch screen |
| Gas supply | O2, N2O, AIR |
| Selectatec bar | Dual positions |
| ACGO | Standard |
| Mechanical Flowmeter | 6 flow tubes for 3 gas |
| By-pass | Standard |
| Ventilator Mode | V-CMV, V-SIMV, P-CMV, P-SIMV, PSV, Manual/Spont |
| Spirometry loop | P-V, P-F, F-V, Reference Loop |
| Spare Cylinder yoke | Optional (O2, N2O ) |
| Li-ion Battery | 1 battery, 2600mAh,
Optional (2 batteries, 5200mAh) |
| Tidal volume (Vt) | 10~1500 ml, optional choice 5~1500 ml |
| Inspiratory pressure (Pinsp) | 5~70 cmH2O |
| Respiratory frequency (Freq) | 4~100 bpm |
| AGSS | Optional |
| Waveforms | Up to 3 waveforms, user configurable |
| Auxiliary power outlets | 3 |
| Wheels | 4, two independent brake wheels |
| Drawers | 2 drawers |
| Reading lamp | LED lighting Included |
| Gas monitor module | Optional includes CO2 and AG Module |
| Built-in Heater | Standard |
| O2 cell | Standard |
| Vaporizer | Optional (Drager/Penlon/Northern) |
| Patient monitor | Optional |
| Suction Device | Optional |
